General
Product TypeCamcorder - 4K
Lens IncludedBody only
Widescreen Video CaptureYes
Camcorder Media TypeFlash card
Optical Sensor TypeExmor R CMOS
Image ProcessorBIONZ X
Digital Video FormatMPEG-2, H.264, XAVC Intra, XAVC Long GOP, AVC
Audio Signal FormatLinear PCM
FeaturesSelectable frame rates, 4 channel audio recording, zebra pattern
AV InterfacesHDMI, 3G HD-SDI
Exposure & White Balance
Light SensitivityISO 2000
Min Illumination0.7 lux
White BalanceCustom, presets
White Balance Presets1500K - 50000K
Max Shutter Speed1/9000 sec
Min Shutter Speed1/3 sec
Gain Selection+12 dB, +18 dB, +3 dB, +6 dB, 0 dB, -3 dB, automatic, + 9 dB
Built-in ND Filters1/4, 1/64, 1/16
Lens System
Lens System MountingSony E-mount
Additional Features
Additional FeaturesSlow motion playback, accessories hot shoe, fast motion recording, super slow motion recording
Viewfinder
Viewfinder TypeElectronic
Viewfinder Color SupportColor
Display
Type3.5" LCD display
Resolution1,560,000 pixels
Display FeaturesRotating
Microphone
Microphone Operation ModeOmni-directional
Connections
Connector Type2 x audio input ( 3 pin XLR ) 1 x HDMI output ( 19 pin HDMI Type A ) 1 x 3G HD-SDI output ( BNC ) 1 x USB ( 4 pin USB Type A ) 1 x USB 2.0 ( mini-USB Type B ) 1 x headphones ( mini-phone stereo 3.5 mm ) 1 x remote control ( sub-mini phone stereo 2.5 mm ) 1 x speakers output 1 x DC power input ( power DC jack )
Memory Card SlotSD card, XQD Memory card
Software
SoftwareDrivers & Utilities
System Requirements for PC Connection
Peripheral DevicesUSB port, CD-ROM drive
Miscellaneous
Included AccessoriesBattery pack, body cap, AC power adapter, eyepiece, USB cable, USB wireless network adapter, remote control stand, wireless remote control, WA adapter bracket
ProtectionSplashproof, dust resistant
Battery
Battery TypeSony BP-U30
Details1 x Sony BP-U30 Li-ion rechargeable battery ( included )
Battery Life DetailsVideo recording - 1 hours ( 4K resolution )
Memory / Storage
Memory Card SlotSD card, XQD Memory card
Supported Memory CardsSD Memory Card, XQD Memory Card
Video CaptureXAVC Intra - 3840 x 2160 - 59.94 fps - 600Mbps XAVC Intra - 3840 x 2160 - 50 fps - 500Mbps XAVC Intra - 3840 x 2160 - 29.97 fps - 300Mbps XAVC Intra - 3840 x 2160 - 23.98 fps - 240Mbps XAVC Intra - 3840 x 2160 - 25 fps - 250Mbps XAVC Intra - 1920 x 1080 - 59.94 fps - 222Mbps XAVC Intra - 1920 x 1080 - 50 fps - 185Mbps XAVC Intra - 1920 x 1080 - 59.94 fps - 111Mbps XAVC Intra - 1920 x 1080 - 50 fps - 111Mbps XAVC Intra - 1920 x 1080 - 29.97 fps - 111Mbps XAVC Long GOP - 3840 x 2160 - 59.94 fps - 150Mbps XAVC Long GOP - 3840 x 2160 - 50 fps - 150Mbps XAVC Long GOP - 3840 x 2160 - 29.97 fps - 100Mbps XAVC Long GOP - 3840 x 2160 - 23.98 fps - 100Mbps XAVC Long GOP - 3840 x 2160 - 25 fps - 100Mbps XAVC Long GOP - 1920 x 1080 - 59.94 fps - 50Mbps XAVC Long GOP - 1920 x 1080 - 50 fps - 50Mbps XAVC Long GOP - 1920 x 1080 - 29.97 fps - 50Mbps XAVC Long GOP - 1920 x 1080 - 23.98 fps - 50Mbps XAVC Long GOP - 1920 x 1080 - 25 fps - 50Mbps XAVC Long GOP - 1920 x 1080 - 59.94 fps - 35Mbps XAVC Long GOP - 1920 x 1080 - 50 fps - 35Mbps XAVC Long GOP - 1920 x 1080 - 29.97 fps - 35Mbps XAVC Long GOP - 1920 x 1080 - 23.98 fps - 35Mbps XAVC Long GOP - 1920 x 1080 - 25 fps - 35Mbps XAVC Long GOP - 1920 x 1080 - 59.94 fps - 25Mbps XAVC Long GOP - 1920 x 1080 - 50 fps - 25Mbps MPEG-2 - 1920 x 1080 - 59.94 fps - 50Mbps MPEG-2 - 1920 x 1080 - 50 fps - 50Mbps MPEG-2 - 1920 x 1080 - 29.97 fps - 50Mbps MPEG-2 - 1920 x 1080 - 23.98 fps - 50Mbps MPEG-2 - 1920 x 1080 - 25 fps - 50 sec
Dimensions & Weight
Width6.1 in
Depth5.5 in
Height9.7 in
Weight4.4 lbs
Environmental Parameters
Min Operating Temperature32 °F
Max Operating Temperature104 °F
Min Storage Temperature-4 °F
Max Storage Temperature140 °F
